A-A-55483A
3.9 Marking. Parts supplied to this CID shall not be marked. The unit package supplied shall be marked
with the manufacturer's standard commercial PIN.
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.029
0.74
.058
1.47
.118
3.00
.195
4.95
.380
9.65
.002
0.05
.030
0.76
.059
1.50
.120
3.05
.200
5.08
.396
10.06
.003
0.08
.031
0.79
.060
1.52
.128
3.25
.230
5.84
.410
10.41
.004
0.10
.035
0.89
.062
1.57
.138
3.51
.236
5.99
.415
10.54
.005
0.13
.038
0.97
.063
1.60
.146
3.71
.250
6.35
.437
11.10
.006
0.15
.041
1.04
.068
1.73
.150
3.81
.256
6.50
.440
11.18
.007
0.18
.043
1.09
.072
1.83
.159
4.04
.296
7.52
.450
11.43
.008
0.20
.047
1.19
.076
1.93
.160
4.06
.297
7.54
.500
12.70
.010
0.25
.050
1.27
.080
2.03
.175
4.45
.316
8.03
.562
14.27
.012
0.30
.051
1.30
.090
2.29
.190
4.83
.323
8.20
1.125
28.58
.015
0.38
.054
1.37
.094
2.39
.192
4.88
.330
8.38
.020
0.51
.055
1.40
.106
2.69
.193
4.90
.350
8.89
.027
0.69
.057
1.45
.112
2.84
.194
4.93
.375
9.53
NOTES:
1. Dimensions are in Inches.
2. Metric equivalents are listed for general information only.
FIGURE 1. Configuration and dimensions.
