MIL-PRF-27/192A
INCHES
MM
INCHES
MM
.086
2.18
.700
17.78
.100
2.54
.750
19.05
.175
4.44
.800
20.32
.300
7.62
.875
22.22
.350
8.89
.950
24.13
.400
10.16
.975
24.76
.425
10.80
1.100
27.94
.525
13.34
1.125
28.58
.550
13.97
1.390
35.31
NOTES:
1.Dimensions are in inches.
2.Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.005 (.13 mm).
4.Marking shall be on the top of the case.
FIGURE 1. Dimensions and configuration Continued.
