INCH-POUND
MIL-PRF-27/195A
18 July 2008
SUPERSEDING
MIL-T-27/195
18 October 1977
PERFORMANCE SPECIFICATION SHEET
TRANSFORMER, POWER, STEPDOWN
Inactive for new design
after 14 February 1997
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the products described
herein shall consist of this specification and MIL-PRF-27.
INCHES
MM
0.08
.003
4.44
.175
5.72
.225
8.26
.325
8.89
.350
10.16
.400
11.43
.450
12.70
.500
13.94
.525
19.97
.550
17.14
.675
20.32
.800
NOTES:
1.Dimensions are in inches.
2.Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.005 (.13 mm).
4.Marking shall be on the top of the case.
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5950
