MIL-PRF-27/25C
CIRCUIT DIAGRAM
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.030 (0.76 mm) for two place decimals.
4. Marking: Type designation, military part number, manufacturers name or code symbol, circuit diagram,
rated voltage and frequency of primary, rated voltages and currents of secondaries, working voltage and date
code to be marked in the space specified on figure 1.
FIGURE 1. Dimensions and configurations - Continued.
2
