MIL-PRF-27/287B
INCHES
MM
INCHES
MM
5.08
.200
0.13
.005
6.35
.250
0.25
.010
7.14
.281
0.38
.015
10.16
.400
0.76
.030
11.13
.438
1.60
.063
14.30
.563
1.85
.073
22.22
.875
2.08
.082
3.96
.156
WV 357V
(SEE TABLE I FOR VALUES OF "X")
CIRCUIT DISGRAM AND MARKING
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the side and on top.
4. Electrical values shall be marked as specified in table I, as applicable.
5. Circuit diagram BB, for series connection join terminals 2 and 3 for parallel connection join
terminals 1 and 2, 3 and 4.
FIGURE 1. Dimensions and configurations Continued.
2
