MIL-PRF-27/314C
Marking location: See figure 1.
Part or Identification Number (PIN): M27/314-(dash number from table I).
TABLE I. Electrical ratings.
Secondary (3-5)
Dash
DC resistance
Voltage
Current 1/
number
(ohms)
(volts)
(amperes)
±25 percent
±3 percent
01
5.0
3.00
0.07
02
6.3
2.38
0.094
03
8.0
1.88
0.16
04
10.0
1.50
0.23
05
12.6
1.19
0.40
06
14.0
1.07
0.60
07
16.0
0.94
0.67
08
18.0
0.83
0.78
09
20.0
0.75
0.90
10
22.0
0.68
1.20
11
25.0
0.60
1.40
12
28.0
0.54
1.90
13
31.0
0.48
2.20
14
35.0
0.43
3.00
15
39.0
0.38
3.50
16
43.0
0.35
4.65
17
48.0
0.31
5.20
18
55.0
0.27
7.50
19
63.0
0.24
8.60
20
70.0
0.212
11.2
21
80.0
0.187
13.6
22
90.0
0.167
20.0
23
100
0.150
22.0
24
110
0.136
28.0
25
123
0.122
33.5
26
138
0.108
46.0
27
157
0.096
53.0
28
175
0.086
70.0
29
200
0.075
87.0
30
220
0.068
118
1/ For 50 Hz operation, reduce secondary current by 10 percent.
VERIFICATION:
Extent of Qualification:
Qualification testing and approval to M27/312-26 or M27/316-30 or M27/322-24 shall be sufficient
to grant qualification approval to MIL-PRF-27/312 through MIL-PRF-27/322, inclusive, all parts.
Qualification testing and approval to M27/314-30 shall be sufficient to grant qualification approval
M27/314-01 through M27/314-30.
