MIL-PRF-27/318C
.188
± .005
.070
± .005
.062
± .005
.094
DASH NUMBERS 03 THRU 30
± .005
.080
± .005
PRIMARY
1
2
DASH NUMBERS 01 AND 02
5
3
4
SECONDARY
CIRCUIT DIAGRAM
Inches
mm
Inches
mm
.005
0.13
.375
9.52
.016
0.41
.470
11.94
.031
0.79
.875
22.22
.062
1.57
1.063
27.00
.070
1.78
2.00
50.8
.080
2.03
2.25
57.2
.094
2.39
2.63
66.8
.164
4.17
3.13
79.5
.188
4.78
4.13
104.9
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the sides of the case.
4. Unless otherwise specified, tolerance shall be .063 (1.60 mm).
5. Electrical values shall be marked as specified in table I, except DCR.
6. The mounting surface can be painted.
FIGURE 1. Dimensions and configurations.
2
