MIL-PRF-27/319C
Marking location: See figure 1.
Part or Identification Number (PIN): M27/319-(dash number from table I).
TABLE I. Electrical ratings.
Secondary (3-5)
Dash
Voltage
Current 1/
DC resistance
number
(volts)
(amperes)
(ohms)
±3 percent
±25 percent
M27/319-
01
6.3
19.00
.012
02
8.0
15.00
.018
03
10.0
12.00
.031
04
12.6
9.53
.041
05
14.0
8.59
.055
06
16.0
7.50
.072
07
18.0
6.68
.080
08
20.0
6.00
0.120
09
22.0
5.45
0.125
10
25.0
4.80
0.182
11
28.0
4.29
0.205
12
31.0
3.87
0.310
13
35.0
3.43
0.350
14
39.0
3.07
0.342
15
43.0
2.79
0.480
16
48.0
2.50
0.660
17
55.0
2.18
0.820
18
63.0
1.91
1.11
19
70.0
1.72
1.20
20
80.0
1.50
1.43
21
90.0
1.34
1.96
22
100
1.20
2.75
23
110
1.09
3.05
24
123
0.970
4.35
25
138
0.870
4.85
26
157
0.760
5.45
27
175
0.685
7.60
28
200
0.600
8.80
29
220
0.546
12.1
1/ For 50 Hz operation, reduce secondary current by 10 percent.
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/312-26 or M27/316-30, and M27/322-24 shall be sufficient
to grant qualification approval to MIL-PRF-27/312 through MIL-PRF-27/322, inclusive, all parts.
Qualification testing and approval to M27/319-29 shall be sufficient to grant qualification approval
M27/319-01 through M27/319-29.
