MIL-PRF-27/321D
Inches
mm
Inches
mm
.005
0.13
.464
11.79
.010
0.25
.625
15.88
.016
0.41
.875
22.22
.031
0.79
1.063
27.00
.062
1.57
2.63
66.8
.070
1.78
2.75
69.8
.080
2.03
3.00
76.2
.094
2.39
3.38
85.8
.125
3.18
3.88
98.6
.188
4.78
4.06
103.1
119.1
4.69
6.35
.250
133.4
5.25
9.52
.375
152.4
6.00
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the sides of the case.
4. Unless otherwise specified, tolerance shall be .063 (1.60 mm).
5. Electrical values shall be marked as specified in table I, except DCR.
6. The mounting surface can be painted.
FIGURE 1. Dimensions and configurations - Continued.
