MIL-PRF-27/322E
Marking location: See figure 1.
Shock (specified pulse): Method 213, MIL-STD-202, test condition G.
Part or Identification Number (PIN): M27/322-(dash number from table I).
TABLE I. Electrical ratings.
Secondary (3-5)
Dash
Voltage
Current 1/
DC resistance
number
(volts)
(amperes)
(ohms)
±3 percent
±25 percent
01
16.0
18.70
0.016
02
18.0
16.70
0.020
03
20.0
15.00
0.023
04
22.0
13.60
0.031
05
25.0
12.00
0.042
06
28.0
10.70
0.046
07
31.0
9.67
0.054
08
35.0
8.59
0.072
09
39.0
7.69
0.080
10
43.0
6.95
0.108
11
48.0
6.26
0.165
12
55.0
5.46
0.175
13
63.0
4.76
0.187
14
70.0
4.29
0.26
15
80.0
3.75
0.30
16
90.0
3.320
0.43
17
100
3.000
0.48
18
110
2.72
0.65
19
123
2.44
0.74
20
138
2.17
1.02
21
157
1.91
1.16
22
175
1.710
1.63
23
200
1.50
1.92
24
220
1.36
2.55
1/ For 50 Hz operation, reduce secondary current by 10 percent.
