MIL-PRF-27/327E
Temperature rise: 40C with 115 volts rms, 60 hertz across (1-2) at an ambient temperature of 90C,
Marking location: See figure 1.
Part or Identification Number (PIN): M27/327-(dash number from table I).
TABLE I. Electrical ratings.
Secondary voltage
Secondary
Secondary
Secondary
Secondary
(series) volts
current
voltage
current
dc resistance
Dash
rms
(series)
(parallel)
(parallel)
each winding
number
amperes
volts rms
amperes
ohms ±25%
(3-6)
(3-5)
(3-5)
01
10.0
1.50
5.0
3.00
0.116
02
12.6
1.19
6.3
2.38
0.167
03
16.0
0.93
8.0
1.86
0.252
04
20.0
0.75
10.0
1.50
0.48
05
24.0
0.60
12.0
1.20
0.58
06
34.0
0.44
17.0
0.88
1.06
07
40.0
0.36
20.0
0.72
1.57
08
56.0
0.27
28.0
0.54
3.5
09
88.0
0.15
44.0
0.30
8.78
10
120.0
0.12
60.0
0.24
14.8
VERIFICATION:
Extent of Qualification:
Qualification testing and approval to M27/326-10 and M27/331-08 shall be sufficient to grant
qualification approval to MIL-PRF-27/326 through MIL-PRF-27/331 inclusive, all parts.
Qualification testing and approval to M27/327-10 shall be sufficient to grant qualification
approval M27/327-01 through M27/327-10.
