MIL-PRF-27/330C
Temperature rise: 40C with 115 volts rms, 60 Hz across (1-2) at an ambient temperature of 90C,
Marking location: See figure 1.
Part or Identification Number (PIN): M27/330-(dash number from table I).
TABLE I. Electrical ratings.
Secondary
Secondary
Secondary
Secondary
Secondary
Volt
voltage
current
voltage
current
dc resistance
amperes
Dash
(series) volts
(series)
(parallel)
(parallel)
each winding
number
rms (3-6)
amperes
volts rms
amperes
ohms ±25%
(3-6)
(3-5)
(3-5)
01
10.0
10.00
5.0
20.00
0.0117
100
02
12.6
10.00
6.3
20.00
0.014
126
03
16.0
8.75
8.0
17.50
0.0223
140
04
20.0
7.00
10.0
14.00
0.0335
140
05
24.0
5.80
12.0
11.60
0.0563
140
06
34.0
4.10
17.0
8.20
0.118
140
07
40.0
3.50
20.0
7.00
0.14
140
08
56.0
2.50
28.0
5.00
0.31
140
09
88.0
1.58
44.0
3.16
0.58
140
10
120.0
1.16
60.0
2.32
1.0
140
VERIFICATION:
Extent of Qualification:
Qualification testing and approval to M27/326-10 and M27/331-08 shall be sufficient to grant
qualification approval to MIL-PRF-27/326 through MIL-PRF-27/331 inclusive, all parts.
Qualification testing and approval to M27/330-10 shall be sufficient to grant qualification
approval M27/330-01 through M27/330-10.
