MIL-PRF-27/333D
Polarity: Additive, with terminals 2 and 3, and 5 and 4 connected.
Marking location: See figure 1.
Part or Identification Number (PIN): M27/333-(dash number from table I).
TABLE I. Electrical ratings.
Secondary voltage
Secondary current
Dash
(3-6) (V rms)
(3-6) (amperes)
number
Series
M27/333
Parallel
Series
Parallel
(CT)
2.00
1.00
5
10
-01
1.58
0.79
6.3
12.6
-02
1.25
0.625
8
16
-03
1.00
0.50
10
20
-04
0.84
0.42
12
24
-05
0.588
0.294
17
34
-06
0.50
0.250
20
40
-07
0.356
0.178
28
56
-08
0.226
0.113
44
88
-09
0.166
0.083
60
120
-10
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/332-10 and M27/337-10 shall be sufficient
to grant qualification approval to MIL-PRF-27/332 through MIL-PRF-27/337, inclusive, all parts.
Qualification testing and approval to M27/333-10 shall be sufficient to grant qualification approval
M27/333-01 through M27/333-10.
