MIL-PRF-27/334D
Polarity: Additive, with terminals 2 and 3, and 5 and 4 connected.
Marking location: See figure 1.
Part or Identification Number (PIN): M27/334-(dash number from table I).
TABLE I. Electrical ratings.
Secondary voltage
Secondary current
Dash
(3-6) (V rms)
(3-6) (amperes)
number
Series
M27/334
Parallel
Series
Parallel
(CT)
5.00
2.50
5
10
-01
4.00
2.00
6.3
12.6
-02
3.12
1.56
8
16
-03
2.50
1.25
10
20
-04
2.08
1.04
12
24
-05
1.47
0.735
17
34
-06
1.25
0.625
20
40
-07
0.892
0.446
28
56
-08
0.568
0.284
44
88
-09
0.416
0.208
60
120
-10
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/332-10 and M27/337-10 shall be sufficient
to grant qualification approval to MIL-PRF-27/332 through MIL-PRF-27/337, inclusive, all parts.
Qualification testing and approval to M27/334-10 shall be sufficient to grant qualification approval
M27/334-01 through M27/334-10.
