MIL-PRF-27/343F
Inches
mm
Dimensions
Ltr
.005
0.13
.010
0.25
Inches
mm
.080
2.03
.115
2.92
G
2.75 �.015
69.85 �.0.38
.169
4.29
H
2.71 �.015
68.83 �.0.38
.187
4.75
J
2.31 �.015
58.67 �.0.38
.200
5.08
K
2.21 �.015
56.13 �.0.38
.250
6.35
L
2.25 �.015
57.15 �.0.38
.380
8.89
M
.750 �.031
19.05 �.0.79
.500
12.70
N
1.00 �.031
25.40 �.0.79
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the top and sides of the case.
4. Dimensional tolerance shall be �.031 (0.79 mm) unless otherwise specified.
5. Dimensions G and H to be measured at top of transformer.
FIGURE 1. Dimensions and configurations - Continued.
