MIL-PRF-27/351E
Voltage (no load ) - Voltage (rated load )
Regulation:
x 100
Voltage (rated load )
Shall not exceed 10 percent
Temperature rise: 40°C maximum with 115 volts, 400 hertz across (1-2) at an ambient temperature
of 90°C.
Marking location: See figure 1.
Part or Identifying Number (PIN). M27/351-(dash number from table I).
TABLE I. Electrical ratings.
Secondary voltage 1/
Secondary current
Dash
(3-4) (V rms) ±5%
(3-4) (amperes rms)
number
M27/351
5.00
5.0
-01
3.57
7.0
-02
2.50
10.0
-03
2.08
12.0
-04
1.79
14.0
-05
1.47
17.0
-06
1.04
24.0
-07
0.89
28.0
-08
0.74
34.0
-09
0.21
115.0
-10
0.890
26.0
-11
1/ One-half of the listed output voltage is available between pins 3 and 5 or 4 and 5.
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/350-11 and M27/354-09 shall be sufficient to grant
qualification approval to MIL-PRF-27/350 through MIL-PRF-27/354 inclusive, all parts.
Qualification testing and approval to M27/351-11 shall be sufficient to grant qualification approval to
M27/351-01 through M27/351-11.
