MIL-PRF-27/352E
Marking location: See figure 1.
Part or Identifying Number (PIN) example: M27/352-(dash number from table I).
TABLE I. Electrical ratings.
Dash
Secondary voltage 1/
Secondary current
number
(3-4) (V rms) ±5%
(3-4) (amperes rms)
M27/352
-01
5.0
10.00
-02
7.0
7.14
-03
10.0
5.00
-04
12.0
4.17
-05
14.0
3.57
-06
17.0
2.94
-07
24.0
2.08
-08
28.0
1.79
-09
34.0
1.47
-10
115.0
0.43
-11
26.0
1.920
-12
5
10.00
1/ One-half of the listed output voltage is available between pins 3 and 5 or pins 4 and 5, except dash
number 12.
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/350-11 and M27/354-09 shall be sufficient to grant
qualification approval to MIL-PRF-27/350 through MIL-PRF-27/354 inclusive, all parts.
Qualification testing and approval to M27/352-12 shall be sufficient to grant qualification approval to
M27/352-01 through M27/352-12.
3
