MIL-PRF-27/353E
Temperature rise: 40°C maximum with 115 volts, 400 hertz across (1-2) at an ambient temperature
of 90°C.
Marking location: See figure 1.
Part or Identifying Number (PIN) example: M27/353-(dash number from table I).
TABLE I. Electrical ratings.
Dash
Secondary voltage 1/
Secondary current
number
(3-4) (V rms) ±5%
(3-4) (amperes rms)
M27/353
-01
7.0
10.00
-02
10.0
7.50
-03
12.0
6.25
-04
14.0
5.36
-05
17.0
4.41
-06
24.0
3.13
-07
28.0
2.68
-08
34.0
2.21
-09
115.0
0.65
-10
26.0
2.880
1/ One-half of the listed output voltage is available between pins 3 and 5 or pins 4 and 5.
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/350-11 and M27/354-09 shall be sufficient to grant
qualification approval to MIL-PRF-27/350 through MIL-PRF-27/354 inclusive, all parts.
Qualification testing and approval to M27/353-10 shall be sufficient to grant qualification approval to
M27/353-01 through M27/353-10.
