MIL-PRF-27/354E
Temperature rise: 40°C maximum with 115 volts, 400 hertz across (1-2) at an ambient temperature
of 90°C.
Marking location: See figure 1.
Part or Identifying Number (PIN) example: M27/354-(dash number from table I).
TABLE I. Electrical ratings.
Dash
Secondary voltage 1/
Secondary current
number
(3-4) (V rms) ±5%
(3-4) (amperes rms)
M27/354
-01
10.0
10.00
-02
12.0
8.33
-03
14.0
7.14
-04
17.0
5.88
-05
24.0
4.17
-06
28.0
3.57
-07
34.0
2.94
-08
115.0
0.87
-09
26.0
3.850
-10
32.0
3.13
1/ One-half of the listed output voltage is available between pins 3 and 5 or pins 4 and 5,
except dash number 10.
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/350-11 and M27/354-09 shall be sufficient to grant
qualification approval to MIL-PRF-27/350 through MIL-PRF-27/354 inclusive, all parts.
Qualification testing and approval to M27/354-10 shall be sufficient to grant qualification approval to
M27/354-01 through M27/354-09.
