MIL-PRF-27/356D
Terminal
B
Dash
A
C
Terminal
diameter
Max.
Insert
number
Max.
±.010
Arrangement
inches
Dia.
±.002
01, 06, 11, 16,
.280
.410
.260
A
.012
21, 26, 31, 36,
(7.11)
(10.41)
(6.6)
41, 46, 51, 56,
61
02, 07, 12, 17,
.340
.500
.350
A
.012
22, 27, 32, 37,
(8.63)
(12.7)
(8.89)
42, 47, 52, 57,
62
03, 08, 13, 18,
.415
.630
.440
A
.016
23, 28, 33, 38,
(10.54)
(16.0)
(11.17)
43, 48, 53, 58,
63
04, 09, 14, 19,
.500
.800
.560
B
.016
24, 29, 34, 39,
(12.70)
(20.32)
(14.22)
44, 49, 54, 59
05, 10, 15, 20,
.635
.950
.670
.138-32
B
.020
25, 30, 35, 40,
(16.12)
(24.13)
(17.0)
UNC-2B
45, 50, 55, 60
.200 Min deep
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the side or on top.
4. For series connection join terminals 2 and 3, for parallel connection join terminals 1 and 3, 2 and 4.
5. Metric equivalents are in parentheses.
FIGURE 1. Dimensions and configurations - Continued.
