MIL-PRF-27/361A
TABLE II. Electrical characteristics.
Frequency response: ±3 dB at
Resonance, 1/
300 Hz to 75 kHz and 1 mW
self resonant
Polarity: Additive
Dash
frequency
with terminals
ZS
ZL
no.
kHz
(below) connected
(ohms)
(ohms)
(min)
01
150 CT (1-3)
150 split (4-7)
1300
(3-4) and (5-6)
02
150 CT (1-3)
600 split (4-7)
1300
(3-4) and (5-6)
03
600 CT (1-3)
600 split (4-7)
600
(3-4) and (5-6)
04
600 CT (1-3)
600 CT (5-7)
600
3 and 5
05
600 CT (1-3)
1,200 split (4-7)
600
(3-4) and (5-6)
06
2,000 CT (1-3)
2,000 CT (5-7)
275
3 and 5
07
2,000 CT (1-3)
8,000 split (4-7)
275
(3-4) and (5-6)
08
10,000 CT (1-3)
10,000 split (4-7)
120
(3-4) and (5-6)
09
10,000 CT (1-3)
10,000 CT (5-7)
120
3 and 5
10
15,000 CT (1-3)
600 split (4-7)
90
(3-4) and (5-6)
1/ Self resonant frequency is measured with secondary's carrying the specified load and the secondary
voltage observed.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-PRF-27, this document references the following:
MIL-STD-202
MIL-STD-1276
MIL-PRF-27/362
MIL-PRF-27/363
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
(Project number 5950-2009-048)
DLA - CC
Review activities
Army - AR, MI
Navy AS, MC, OS, SH
Air Force 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil.
4
