INCH-POUND
MIL-PRF-27/43C
18 January 2010
SUPERSEDING
MIL-PRF-27/43B
7 February 1984
PERFORMANCE SPECIFICATION SHEET
TRANSFORMERS, POWER, 9 VOLT AMPERES, 400 HZ
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The complete requirements for procuring the transformer described herein shall consist of this
document and the latest issue of specification MIL-PRF-27.
A
A
B
B
C
C
2
2
3
3
1
4
1
4
B
C
C
A
B
A
5
5
6
6
.138-32 UNC-2B
.138-32 UNC-2B
X .25 DEPTH MIN.
X .25 DEPTH MIN.
D
D
E
E
G
F
F
CONFIGURATION A
CONFIGURATION B
3
1
"X" VOLTAGE CT
115 V
4
400 HZ
"X" mA OR A
5
2
Dim
Inches
Millimeters
MAX W.V. , "X"V"
MAX ALT 70 .000
A
1.09 Max
27.2
(SEE TABLE I FOR VALUE OF "X")
B
.800
20.32
CIRCUIT DIAGRAM AND MARKING
C
.600
15.24
D
.032 ±.002
0.81 ±0.05
.25
6.4
E
.13
3.3
F
1.03 Max
26.2
.03
0.8
G
.02
0.5
FIGURE 1. Dimensions and configurations
