MIL-PRF-27/53D
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/49-44 A or B, M27/51-44 A or B, M27/53-44 A or B, M27/56-44 and
M27/66-27 shall be sufficient to grant qualification approval to MIL-PRF-27/48 through MIL-PRF-27/66
inclusive, all parts.
Qualification testing and approval to M27/53-44 shall be sufficient to grant qualification approval to M27/53-01
through M27/53-44.
Part or Identifying Number (PIN) example:
27/53
-01
M
|
|
|
MIL specification item
Specification sheet no.
Dash no.
TABLE I. Electrical ratings.
Secondary voltage
Secondary current
Working voltage
(3-5) (V rms) ±3%
Dash number
(3-5) (amps rms)
(V rms max)
01 A or B
6
1.000
325
02 A or B
6.3
0.953
325
03 A or B
7
0.857
325
04 A or B
7.5
0.800
325
05 A or B
8
0.750
325
06 A or B
9
0.667
325
07 A or B
10
0.600
325
08 A or B
11
0.545
325
09 A or B
12
0.500
325
10 A or B
12.6
0.476
325
11 A or B
13
0.462
325
12 A or B
15
0.400
325
13 A or B
16
0.375
325
14 A or B
18
0.333
325
15 A or B
20
0.300
325
16 A or B
22
0.272
325
17 A or B
24
0.250
325
18 A or B
26
0.230
325
19 A or B
28
0.214
325
20 A or B
30
0.200
325
21 A or B
33
0.182
325
22 A or B
36
0.167
325
23 A or B
39
0.154
325
24 A or B
43
0.140
325
25 A or B
47
0.128
325
26 A or B
51
0.118
325
27 A or B
56
0.107
325
28 A or B
62
0.097
325
29 A or B
68
0.088
325
30 A or B
75
0.080
325
31 A or B
82
0.073
325
32 A or B
91
0.066
325
33 A or B
100
0.060
325
34 A or B
110
0.055
325
35 A or B
115
0.052
325
36 A or B
120
0.050
325
37 A or B
130
0.046
325
38 A or B
150
0.040
325
39 A or B
180
0.033
325
40 A or B
200
0.030
440
41 A or B
220
0.027
440
42 A or B
240
0.025
440
43 A or B
270
0.022
580
44 A or B
300
0.020
580
3
