MIL-PRF-27/97D
REQUIREMENTS:
Electrical ratings: See table I.
Primary power level: 125 mW.
TABLE I. Electrical ratings.
Primary dc
Secondary
Dash
Circuit
Primary
Secondary
Primary
resistance
dc
Working
±25 percent
number
diagram
impedance
Impedance
dc current
resistance
voltage
± 25 percent
(ohms)
(ohms)
(mA)
(ohms)
(volts)
(ohms)
01
A
2,000 CT
(4-5) 8,000
3
200
(4-(5+6)-7)
49
(6-7) 8,000
450
02
B
10 k
100
1
1,000
10
50
Design and construction:
Dimensions and configuration: See figure 1.
Duty cycle: Continuous.
Terminals: Pin for printed circuit.
Material: Type D in accordance with MIL-STD-1276.
Diameter: .016 inch.
Length: 1.000 ± .250 inch.
Weight: 2.4 grams maximum.
Operating temperature range: -55°C to +105°C.
Altitude: 70,000 feet.
Terminal strength: MIL-STD-202, method 211, test condition A, 2 pounds.
Dielectric withstanding voltage:
At sea level: 100 volts rms.
At reduced barometric pressure: 100 volts rms.
Electrical characteristics:
Harmonic distortion: Total harmonic content of output 5 percent at 1 kHz.
No load (CT voltage balance only): With 10 volts, 10 kHz applied to (1-3), unbalance (4-5) and (6-7) shall be 3
percent, maximum.
Self-resonant frequency: See table II.
