MIL-PRF-39010/6E
TABLE I. Electrical characteristics (initial) and dash numbers - Continued.
Rated
DC
Q
Test
Self-
Dash
Inductance
Inductance
µH
resistance
minimum
frequency
resonant
number
tolerance
dc
(25°C)
± percent
(MHz)
1/
current
frequency
(mA) 2/
minimum
maximum
(MHz)
(ohms)
300
2.00
110
7.9
33
5, 10
3.30
B3R3**
280
2.30
100
7.9
33
5
3.60
B3R6**
280
2.30
100
7.9
33
5, 10
3.90
B3R9**
260
2.60
90
7.9
33
5
4.30
B4R3**
B4R7**
4.70
5, 10
33
7.9
90
2.60
260
1/ The complete dash number will include two additional letters (indicated by **). The first additional
letter will indicate the inductance tolerance and the second additional letter will indicate the product
level (e.g., C, M, P, R, S) and will be added to the end of the dash number.
2/ The rated dc current is based on 90°C ambient temperature with a 35°C rise.
TABLE II. Electrical characteristics (final). 1/
Inspection
Allowable variation from
Allowable percent from specified
group
initial measurement
minimum value in electrical
characteristics (initial) table
Inductance
DC resistance
Self-resonant
Q
(percent)
frequency
Qualification
inspection
±2
Group II
-10
±(3% +.001 ohm)
±5
2/
Group IV
-10
±(2% +.001 ohm)
±5
-15
Group V
2/
Quality
conformance
inspection
Group B
±(2% +.001 ohm)
±5
2/
Subgroup 1
-15
±2
Subgroup 3
-10
±(3% +.001 ohm)
±5
Subgroup 4
-10
2/
Test fixture allowance of +.01 µH shall be added to all change in inductance limits ±( _
1/
percent +.01 µH).
2/ The self-resonant frequency shall be not less than the value specified in table I.
