INCH - POUND
MIL-PRF-83446/11C
1 September 2006
SUPERSEDING
MIL-PRF-83446/11B
20 February 1985
PERFORMANCE SPECIFICATION SHEET
COILS, RADIO FREQUENCY, CHIP, SHIELDED, FIXED
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the products described
herein shall consist of this specification and MIL-PRF-83446.
For dash numbers 01
through 61 (with tabs)
Ltr
Inches
mm
3.94 ±0.20
A
.155 ±.008
3.18 ±0.20
B
.125 ±.008
C
.130 max
3.30 max
.037 ±.003
0.94 ±0.08
D
0.51 ±0.13
E
.020 ±.005
F
.040 +.015
1.02 +0.13
-.010
-0.25
G
.073 Min
1.85 Min
.005 ±.002
0.13 ±0.05
H
For dash numbers 62 through
122 (without tabs)
Ltr
Inches
mm
3.94 ±0.20
A
.155 ±.008
3.18 ±0.20
B
.125 ±.008
C
.140 max
3.556 max
D
.037 +.003
0.94 +0.08
-.012
-0.31
0.51 ±0.13
E
.020 ±.005
G
.073 Min
1.85 Min
.005 ±.002
0.13 ±0.05
H 1/
1/ Applies to lead frame design only.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Fixed, shielded, chip coil.
AMSC N/A
FSC 5950
