MIL-T-27/2028
Inches |
mm |
Inches |
mm |
.005 |
0.13 |
.780 |
19.81 |
.030 |
0.76 |
1.125 |
28.58 |
.031 |
0.79 |
1.281 |
32.54 |
.062 |
1.57 |
1.437 |
36.50 |
.125 |
3.18 |
1.500 |
37.10 |
.157 |
3.99 |
1.657 |
42.09 |
.188 |
4.78 |
1.750 |
44.45 |
.219 |
5.56 |
2.000 |
50.80 |
.437 |
11.10 |
2.250 |
57.15 |
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance on case dimensions is ±.016 inch (0.41 mm).
4. Marking shall be on the sides of the case.
FIGURE 1. Dimensions and configurations - Continued
