MIL-PRF-27/194B
WORKING VOLTAGE: 175 V MAX
CIRCUIT DIAGRAM AND MARKING
INCHES
INCHE
INCHES
MM
MM
MM
S
.003
0.08
.275
6.98
.675
17.14
.010
0.25
.300
7.62
.740
18.80
.025
0.64
.375
9.52
.825
20.96
.050
1.27
.400
10.16
1.000
25.40
.086
2.18
.475
12.06
1.150
29.21
.100
2.54
.500
12.70
1.200
30.48
.175
4.44
.550
13.97
1.250
31.75
.200
5.08
.575
14.60
1.275
32.38
.225
5.72
.600
15.24
1.300
33.02
.250
6.35
.650
16.51
1.390
35.31
NOTES:
1.Dimensions are in inches.
2.Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.005 (.13 mm).
4.Marking shall be on the top of the case.
FIGURE 1. Dimensions and configuration Continued.
2
