MIL-PRF-27/194B
Polarity: Additive with terminals 9 and 8, and 2 and 3 connected.
Temperature rise: 40°C with 60 volts rms, 7.7 kilohertz across (14-15) at specified ambient
temperature. (see table I).
Vibration (high frequency): MIL-STD-202, method 204.
Shock (specified pulse): MIL-STD-202, method 213, test condition A.
VERIFICATION:
Qualification inspection: Not applicable for this specification sheet.
Quality conformance inspection: Groups A and B tests of MIL-PRF-27 shall be applicable.
Marking location: See figure 1.
Part or Identifying Number (PIN): M27/194-(dash number from Table I).
TABLE I. Temperature characteristics.
Operating
Type
Ambient
Temperature
Dash no.
temperature
designation
temperature
rise
range
01
TF5S03ZZ
90°C
40°C
-55°C to +130°C
02
TF5T03ZZ
130°C
40°C
-55°C to +170°C
