MIL-PRF-27/316C
Marking location: See figure 1.
Part number: M27/316-(dash number from table I).
TABLE I. Electrical ratings.
Secondary (3-5)
Dash
Voltage
Current 1/
DC resistance
number
(volts)
(amperes)
(ohms)
±3 percent
±25 percent
01
5.0
6.00
0.04
02
6.3
4.76
0.06
03
8.0
3.76
0.08
04
10.0
3.00
0.14
05
12.6
2.38
0.20
06
14.0
2.15
0.23
07
16.0
1.87
0.28
08
18.0
1.67
0.38
09
20.0
1.50
0.40
10
22.0
1.36
0.55
11
25.0
1.20
0.70
12
28.0
1.07
0.94
13
31.0
0.97
0.96
14
35.0
0.86
1.40
15
39.0
0.77
1.62
16
43.0
0.70
2.15
17
48.0
0.63
2.40
18
55.0
0.55
3.50
19
63.0
0.48
3.90
20
70.0
.429
5.5
21
80.0
.375
6.4
22
90.0
.332
8.6
23
100
.300
10.0
24
110
.272
13.6
25
123
.244
15.3
26
138
.217
21.0
27
157
.191
24.5
28
175
.171
35.0
29
200
.150
40.0
30
220
.136
57.0
1/ For 50 Hz operation, reduce secondary current by 10 percent.
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/312-26 or M27/316-30 or M27/322-24 shall be sufficient
to grant qualification approval to MIL-PRF-27/312 through MIL-PRF-27/322-30, inclusive, all parts.
Qualification testing and approval to M27/316-30 shall be sufficient to grant qualification approval
M27/316-01 through M27/316-30.
3
