INCH-POUND
MIL-PRF-27/341E
3 December 2010
SUPERSEDING
MIL-PRF-27/341D
22 January 1992
PERFORMANCE SPECIFICATION SHEET
TRANSFORMERS, POWER, 24 VOLTAMPERES, 400 HZ
This specification is approved for use by all Departments
and agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-PRF-27.
Dimensions
Inches
mm
Ltr
.005
0.13
Inches
mm
.010
0.25
.031
0.79
G
1.47 ±.015
37.3 ±0.38
.062
1.57
H
1.28 ±.015
32.5 ±0.38
.116
2.95
J
1.40 ±.015
35.6 ±0.38
.125
3.18
K
1.03 ±.015
26.2 ±0.38
.169
4.29
L
1.22 ±.015
31.3 ±0.38
.187
4.75
M
.250 ±.031
6.35 ±0.79
.250
6.35
.375
9.53
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the top and sides of the case.
4. Dimensional tolerance shall be ±.031 unless otherwise specified.
5. Dimensions G and H to be measured at top of transformer.
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5950
