INCH-POUND
MIL-PRF-27/360A
22 April 2011
SUPERSEDING
MIL-PRF-27/360
5 February 1985
PERFORMANCE SPECIFICATION
TRANSFORMERS, POWER, 15 VA,
ELECTROSTATIC SHIELDED
This specification is approved for use by all Departments
and agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist
of this specification sheet and the latest issue of MIL-PRF-27.
+.000
+.000
2.312
3.125
- .125
- .188
.375
1.688
± .063
± .016
2.062
2
1
+.000
- .125
7
3
6
1.438
± .016
4
5
INCHES
MM
.005
0.13
.016
0.45
.875
.062
1.57
± .063
.138-32 UNC-2A X .375 ± .063
.063
1.60
(4 PLACES)
.070
1.78
.070
.125
3.18
3
"X" Vrms. PARALLEL
± .005
.138
3.51
1
.188
4.78
.062
"Y" Vrms. SERIES
5
115 V rms
.375
22.23
± .005
50-60 Hz
"Z" AMPERES, PARALLEL
4
1.483
37.67
TERMINAL DIMENSION
1.688
42.88
2
2.062
52.37
"W" AMPERES, SERIES
6
2.312
58.72
SEE NOTE 5
3.125
79.38
WORKING VOLTAGE 535 VOLTS PEAK
CIRCUIT DIAGRAM AND MARKING
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking shall be on the side of the case.
4. Primary and secondary electrical values shall be marked as specified in table I, as applicable.
5. The number of terminals shall be as shown in circuit diagram "A" and "B".
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5950
