MIL-PRF-27/360A
Polarity: Additive with terminals 2 and 3 connected and 5 and 4 connected.
Electrostatic shielding: The voltage ratio shall be a minimum of 5 to 1 at 20 kHz.
Temperature rise: 40C with 115 volts rms, 60 hertz across (1-2) at an ambient temperature of 90C,
Marking location: See figure 1.
Part or Identifying Number (PIN): M27/360- (dash number from table I).
TABLE I. Electrical ratings.
Secondary
Secondary
Secondary
Secondary
Secondary voltage
current
voltage
current
dc resistance
Dash
(series) volts
(series)
(parallel)
(parallel)
each winding
no.
rms (3-6)
amperes
volts rms
amperes
ohms ±25%
(3-6)
(3-5)
(3-5)
01
12.6
1.19
6.3
2.38
0.167
VERIFICATION:
Extent of qualification:
Qualification by similarity: Qualification testing and approval to M27/327-02 shall be sufficient to
permit qualification inspection by similarity in accordance with MIL-PRF-27.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
