MIL-PRF-27/365A
Diameter: .64 mm (.025 inch).
Weight: 8 grams, maximum.
Operating temperature range: -55°C to +130°C.
Terminal strength: MIL-STD-202, method 211, test condition A, 2 pounds.
Dielectric withstanding voltage:
At sea level: 500 volts rms.
At reduced barometric pressure: 500 volts rms.
Electrical characteristics: See table I.
No load (centertap unbalanced only): ±1 percent with 5 volts, 5 kilohertz across the primary.
Harmonic distortion: Total harmonic content of the output shall be a maximum 5 percent at the
specified power level and primary dc current (see table I).
Insertion loss: At the specified power level (see table I), the insertion loss shall be a maximum of
3 dB.
Frequency response: ±2 dB at the rated source and load impedances with 15 milliwatt level
output and a reference frequency of 1 kilohertz.
Shock (high frequency): MIL-STD-202, method 213, test condition I.
Marking location: See figure 1.
Part or Identifying Number (PIN): M27/365- (dash number from table I).
TABLE I. Electrical ratings.
Primary
Secondary
Primary
Secondary
impedance
Primary
Power level
impedance
dc
dc
Dash
(ohms)(1-3)
unbalanced
at 200 Hz
(ohms)
resistance
Fig.
resistance
no.
+15%, -20%
dc current
(max)
(4-6)
±20%
±20%
1/
(mA)
(watts)
(ohms)
(ohms)
01
600 CT
600 CT
7
.015
50
65
A
02
600 CT
600 CT
7
.015
50
65
B
1/
Primary impedance (terminals 1-3) measured at power level of 15 mW and 0 dc current at
frequency range of 300 Hz to 10 kHz.
3
