MIL-PRF-27/56G
.234 DIA. MAX
.164-32 UNC-2A
1
2
2-MTG. STUDS
.250
3
4
.250
5
3
1
"X" VOLTAGE CT
115 V
4
"X" mA OR A
400 H z
.125
5 MAX W.V. "X" V
2
.250
MAX ALT 70,000'
1.000
± .031
.344
(SEE TABLE I FOR VALUE OF "X"
± .031
CIRCUIT DIAGRAM AND MARKING
.312
MAX
1.125
0.097
± .031
MAX
.312
MAX
1.375
± .031
CONFIGURATION B
Inches
mm
.031
0.79
.097
2.46
.125
3.18
.164
4.17
.234
5.94
.250
6.35
.312
7.92
.344
8.74
1.000
25.40
1.125
28.58
1.375
34.92
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Tolerance on terminal position dimensions is ±.015 (0.38 mm).
4. Marking shall be on the side of the case.
5. Terminals are color coded for permanent identification in addition to terminal marking shown.
6. Secondary electrical values shall be marked as specified in table I, as applicable.
FIGURE 1. Dimensions and configuration - Continued.
2
