MIL-PRF-27/56G
VERIFICATION:
Extent of qualification:
Qualification testing and approval to M27/49-44 A or B, M27/51-44 A or B, M27/53-44 A or B, M27/56-44 and
M27/66-27 shall be sufficient to grant qualification approval to MIL-PRF-27/48 through MIL-PRF-27/66
inclusive, all parts.
Qualification testing and approval to M27/56-44 shall be sufficient to grant qualification approval to M27/56-01
through M27/56-44. Qualification testing and approval to M27/56-88 shall be sufficient to grant qualification
approval to M27/56-45 through M27/56-88.
Part or Identifying Number (PIN) example:
27/56
-01
M
|
|
|
MIL specification item
Specification sheet no.
Dash no.
TABLE I. Electrical ratings.
Secondary voltage
Secondary current
Working voltage
(3-5) (V rms) 3%
Dash number
(3-5) (amps rms)
(V rms max)
Configuration
01
6
4.167
325
A
02
6.3
3.968
325
A
03
7
3.571
325
A
04
7.5
3.333
325
A
05
8
3.125
325
A
06
9
2.778
325
A
07
10
2.500
325
A
08
11
2.273
325
A
09
12
2.083
325
A
10
12.6
1.984
325
A
11
13
1.923
325
A
12
15
1.667
325
A
13
16
1.563
325
A
14
18
1.389
325
A
15
20
1.250
325
A
16
22
1.136
325
A
17
24
1.042
325
A
18
26
0.962
325
A
19
28
0.893
325
A
20
30
0.833
325
A
21
33
0.758
325
A
22
36
0.694
325
A
23
39
0.641
325
A
24
43
0.581
325
A
25
47
0.532
325
A
26
51
0.490
325
A
27
56
0.446
325
A
28
62
0.403
325
A
29
68
0.367
325
A
30
75
0.333
325
A
31
82
0.305
325
A
32
91
0.275
325
A
33
100
0.250
325
A
34
110
0.227
325
A
35
115
0.218
325
A
36
120
0.208
325
A
37
130
0.192
325
A
38
150
0.166
325
A
39
180
0.139
325
A
40
200
0.125
440
A
41
220
0.113
440
A
42
240
0.104
440
A
43
270
0.093
580
A
44
300
0.083
580
A
