MIL-PRF-83446/12A
TABLE I. Electrical characteristics (initial) and dash numbers.
Self
Test
Current
DC
Inductance
Q
Q
Dash
Incremental
resonant
frequency
(max)
resistance
±10%
(typ)
(min)
number
frequency
current
(MHz)
mA
(max)
(µH)
(min)
3/
1/
2/
ohms
MHz
01
0.010
36
60
200
1200
0.020
750
----
02
0.012
30
60
200
1200
0.025
750
----
03
0.015
30
60
200
1200
0.035
750
----
04
0.018
30
60
200
1200
0.040
750
----
05
0.022
45
60
200
1000
0.045
750
----
06
0.027
30
60
200
1000
0.050
750
----
07
0.033
30
60
200
1000
0.055
640
----
08
0.039
30
55
200
1000
0.060
600
----
09
0.047
30
55
100
1000
0.065
550
----
10
0.056
30
55
100
1000
0.060
520
----
11
0.068
20
55
100
800
0.060
480
----
12
0.082
20
55
100
800
0.060
470
----
13
0.100
30
50
25.0
750
0.160
460
----
14
0.120
32
50
25.0
700
0.170
455
----
15
0.150
40
50
25.0
650
0.190
450
----
16
0.180
30
50
25.0
600
0.200
430
----
17
0.220
42
50
25.0
570
0.300
350
----
18
0.270
40
50
25.0
500
0.350
310
----
19
0.330
36
50
25.0
400
0.720
280
----
20
0.390
35
50
25.0
380
0.800
250
----
21
0.470
38
50
25.0
450
1.26
230
----
22
0.560
40
50
25.0
400
1.30
220
----
23
0.680
40
50
25.0
300
1.40
210
----
24
0.820
40
45
25.0
250
1.50
200
----
25
1.0
37
45
25.0
220
1.60
200
----
26
1.2
35
45
7.9
175
1.70
20
----
27
1.5
31
45
7.9
135
2.50
190
----
28
1.8
30
45
7.9
120
3.00
185
----
29
2.2
40
45
7.9
95
3.30
180
----
