MIL-T-27/223C
Inches |
mm |
.002 |
0.05 |
.015 |
0.38 |
.032 |
0.81 |
.138 |
3.51 |
.187 |
4.75 |
1.375 |
34.92 |
1.656 |
42.06 |
1.750 |
44.45 |
1.875 |
47.62 |
2.250 |
57.15 |
FIGURE 1. Dimensions and configurations - continued
Inches mm
.250 6.35
.500 12.70
1.000 25.40
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
2
