MIL-PRF-15305F
TABLE IV. Qualification inspection.
Number of
Requirement
Method
Sample units to be
Inspection
paragraph
paragraph
Inspected 4/
Group I
Thermal shock - - - - - - - - - - - - - - - - -
Operating torque (when applicable) - - -
Electrical characteristics - - - - - - - - - - -
Inductance - - - - - - - - - - - - - - - - - -
Q -------------------------
Self resonant frequency - - - - - - - - - -
All sample
DC resistance - - - - - - - - - - - - - - - -
units
Other electrical characteristics
except
(3.1) (initial):
Groups V & VI
Percent coupling (when specified) - - -
Incremental current inductance
Change (when specified) - - - - - - - -
Effective parallel resistance
(when specified) - - - - - - - - - - - - - - -
Visual and mechanical examination
(external) - - - - - - - - -- - - - - - - - - - - -
and 3.24
Group II
Temperature rise - - - - - - - - - - - - - - - -
Overload 2/ - - - - - - - - - - - - - - - - - - - -
Resistance to soldering heat - - - - - - - -
6
Electrical characteristics (final) - - - - - - -
Inductance - - - - - - - - - - - - - - - - - - -
Q --------------------------
Group III
Life - - - - - - - - - - - - - - - - - - - - - - - - - -
6
Group IV
Low temperature storage (-65°C) - - - -
Vibration - - - - - - - - - - - - - - - - - - - - - -
Shock (specified pulse) - - - - - - - - - - - -
Moisture resistance - - - - - - - - - - - - - -
Electrical characteristics (final) - - - - - -
Visual and mechanical examination
6
(external) - - - - - - - - - - - - - - - - - -
and 3.24
Visual and mechanical examination
(internal) (only 2 samples need be
dissected) - - - - - - - - - - -
